Fujitsu AUUA4TLAV1 Compact Cassette Indoor Unit for Heat-Recovery/Heat Pump VRF System 4k Cool/4.4k Heat 230/1

    • Connection Pipe Diameter - Liquid (Flare) 1/4"
    • Connection Pipe Diameter - Gas (Flare) 1/2"
    • 208/230/1
    • Drain (ID; OD) 9/16
    • Drain-Pump Built-In
    • 9-5/8" × 22-7/16" × 22-7/16"
Item#:
AUUA4TLAV1
Manufacturer Item:
AUUA4TLAV1
Manufacturer:
FUJITSU
Fujitsu ASUA4TLAV1 Airstage Wall Mount Indoor Evaporator Cool 30,000k BTU 4,400 Heat 208/1
  • Connection Pipe Diameter - Liquid (Flare) 3/8"
  • Connection Pipe Diameter - Gas (Flare) 5/8"
  • 208/230/1
  • Drain (ID; OD) 9/16
  • Drain-Pump Optional
Item#:
ASUB30TLAV1
Manufacturer Item:
ASUB30TLAV1
Manufacturer:
FUJITSU
Fujitsu AOU60RLAVM Airstage Condenser Heat Pump Cool 60k BTU 66k BTU Heat 208/1 VAC R410A VRF
  • Power source Phase 1-phase
  • Voltage 208 / 230 V
  • Frequency 60 Hz
  • Capacity Cooling 60,000 BTU/h
  • Heating 66,000 BTU/h
  • EER (Non-Ducted/Ducted) Cooling 10.8 / 10.4 Btu/hW
  • SEER (Non-Ducted/Ducted) Cooling 18.5 / 16.5 Btu/hW
  • COP (Non-Ducted/Ducted) Heating 3.65 / 3.60 W/W
  • HSPF (Non-Ducted/Ducted) Heating 11.3 / 11.0 Btu/hW
  • Air Flow Rate 4,827 CFM (8,200 m/³h)
  • Sound Pressure Level*2 Cooling 57 dB(A)
  • Heating 57 dB(A)
  • Net Dimensions Height 52-1/2" (1,334 mm)
  • Width 38-3/16" (970 mm)
  • Depth 14-9/16" (370 mm)
  • Net Weight 269 lbs (122 kg)
  • Refrigerant Type R410A
  • Charge 11.7 lbs (5.3 kg)
  • Connection Pipe Diameter Liquid 3/8" (9.52 mm)
  • Discharge Gas 3/4" (19.05 mm)
  • Operation Range Cooling 23 to 115 °FDB (-5 to 46 °CDB)
  • Heating -4 to 70 °FDB (-20 to 21 °CDB)
Item#:
AOU60RLAVM
Manufacturer Item:
AOU60RLAVM
Manufacturer:
FUJITSU
Fujitsu AOUA96RLBV1 Airstage Condenser Heat Pump Cool 96k BTU 108k BTU Heat 208/3 VAC R410A VRF
  • Power source Phase 3-phase
  • Voltage 208 / 230 V
  • Frequency 60 Hz
  • Capacity Cooling 96,000 BTU/h
  • 28.1 kW
  • Heating 108,000 BTU/h
  • 31.7 kW
  • Input Power Cooling 7.67 kW
  • Heating 7.90 kW
  • EER (Non-Ducted/Ducted) Cooling 11.7 / 11.3 Btu/hW
  • IEER (Non-Ducted/Ducted) Cooling 23.6 / 20.2 Btu/hW
  • COP (Non-Ducted/Ducted) Heating 3.72 / 3.60 W/W
  • Air Flow Rate 6,533 CFM (11,100 m/³h)
  • Sound Pressure Level*2 Cooling 59 dB(A)
  • Heating 59 dB(A)
  • Maximum external static pressure 0.32 in.WG (80 Pa)
  • Compressor motor output 7.5 kW
  • Net Dimensions Height 66-9/16" (1,690 mm)
  • Width 36-5/8" (930 mm)
  • Depth 30-1/8" (765 mm)
  • Net Weight 564 lbs (256 kg)
  • Refrigerant Type R410A
  • Charge 25.79 lbs (11.70 kg)
  • Connection Pipe Diameter Liquid 1/2" (12.70 mm)
  • Discharge Gas 7/8" (22.22 mm)
  • Operation Range Cooling 5 to 115 °FDB (-15 to 46 °CDB)
  • Heating -4 to 70 °FDB (-20 to 21 °CDB)
Item#:
AOUA96RLBV1
Manufacturer Item:
AOUA96RLBV1
Manufacturer:
FUJITSU
Fujitsu AOUA72RLBV1 Airstage Condenser Heat Pump Cool 72k BTU 81k BTU Heat 208/3 VAC R410A VRF
  • Power source Phase 3-phase
  • Voltage 208 / 230 V
  • Frequency 60 Hz
  • Capacity Cooling 72,000 BTU/h
  • 21.1 kW
  • Heating 81,000 BTU/h
  • 23.7 kW
  • Input Power Cooling 5.37 kW
  • Heating 5.39 kW
  • EER (Non-Ducted/Ducted) Cooling 12.5 / 12.3 Btu/hW
  • IEER (Non-Ducted/Ducted) Cooling 24.1 / 20.0 Btu/hW
  • COP (Non-Ducted/Ducted) Heating 4.06 / 3.64 W/W
  • Air Flow Rate 6,533 CFM (11,100 m/³h)
  • Sound Pressure Level*2 Cooling 57 dB(A)
  • Heating 58 dB(A)
  • MaXimum eXternal static pressure 0.32 in.WG (80 Pa)
  • Compressor motor output 7.5 kW
  • Net Dimensions Height 66-9/16" (1,690 mm)
  • Width 36-5/8" (930 mm)
  • Depth 30-1/8" (765 mm)
  • Net Weight 564 lbs (256 kg)
  • Refrigerant Type R410A
  • Charge 25.79 lbs (11.70 kg)
  • Connection Pipe Diameter Liquid 1/2" (12.70 mm)
  • Discharge Gas 7/8" (22.22 mm)
  • Operation Range Cooling 5 to 115 °FDB (-15 to 46 °CDB)
  • Heating -4 to 70 °FDB (-20 to 21 °CDB)
Item#:
AOUA72RLBV1
Manufacturer Item:
AOUA72RLBV1
Manufacturer:
FUJITSU
Fujitsu ASUA4TLAV1 Airstage Wall Mount Indoor Evaporator Cool 4,000k BTU 4,400 Heat 208/1
  • Connection Pipe Diameter - Liquid (Flare) 1/4
  • Connection Pipe Diameter - Gas (Flare) 3/8
  • 208/230/1
  • Drain (ID; OD) 9/16
  • Drain-Pump Optional
Item#:
ASUA4TLAV1
Manufacturer Item:
ASUA4TLAV1
Manufacturer:
FUJITSU
Fujitsu AOU48RLAVM Airstage Condenser Heat Pump Cool 48k BTU 54k BTU Heat 208/1 VAC R410A VRF
  • Rating Capacity Range 4
  • MaXimum Connectable Indoor Unit*1 1-8
  • Power source Phase 1-phase
  • Voltage 208 / 230 V
  • Frequency 60 Hz
  • Capacity Cooling 48,000 BTU/h
  • Heating 54,000 BTU/h
  • EER (Non-Ducted/Ducted) Cooling 12.5 / 11.8 Btu/hW
  • SEER (Non-Ducted/Ducted) Cooling 19.8 / 18.1 Btu/hW
  • COP (Non-Ducted/Ducted) Heating 3.88 / 3.64 W/W
  • HSPF (Non-Ducted/Ducted) Heating 11.4 / 10.9 Btu/hW
  • Air Flow Rate 3,767 CFM (6,400 m/³h)
  • Sound Pressure Level*2 Cooling 51 dB(A)
  • Heating 53 dB(A)
  • Net Dimensions Height 52-1/2" (1,334 mm)
  • Width 38-3/16" (970 mm)
  • Depth 14-9/16" (370 mm)
  • Net Weight 262 lbs (119 kg)
  • Refrigerant Type R410A
  • Charge 11.7 lbs (5.3 kg)
  • Connection Pipe Diameter Liquid 3/8" (9.52 mm)
  • Discharge Gas 5/8" (15.88 mm)
  • Operation Range Cooling 23 to 115 °FDB (-5 to 46 °CDB)
  • Heating -4 to 70 °FDB (-20 to 21 °CDB)
Item#:
AOU48RLAVM
Manufacturer Item:
AOU48LAVM
Manufacturer:
FUJITSU
Fujitsu AOUA120TLBV Airstage Condenser Heat Pump Cool 120k BTU 135k BTU Heat 208/3 VAC R410A VRF
  • Power source Phase 3-phase
  • Voltage 208 / 230 V
  • Frequency 60 Hz
  • Capacity Cooling 120,000 BTU/h
  • 35.2 kW
  • Heating 135,000 BTU/h
  • 39.6 kW
  • Input Power Cooling 9.75 kW
  • Heating 10.11 kW
  • EER (Non-Ducted/Ducted) Cooling 11.3 / 11.3 Btu/hW
  • IEER (Non-Ducted/Ducted) Cooling 23.8 / 20.1 Btu/hW
  • COP (Non-Ducted/Ducted) Heating 3.61 /3.49 W/W
  • SCHE (Non-Ducted/Ducted) 25.4 / 25.8 Btu/hW
  • Air Flow Rate 7,652 CFM (13,000 m/³h)
  • Sound Pressure Level*2 Cooling 61 dB(A)
  • Heating 62 dB(A)
  • Maximum external static pressure 0.32 in.WG (80 Pa)
  • Compressor motor output 11.0 kW
  • Net Dimensions Height 66-9/16" (1,690 mm)
  • Width 48-13/16" (1,240 mm)
  • Depth 30-1/8" (765 mm)
  • Net Weight 639 lbs (290 kg)
  • Refrigerant Type R410A
  • Charge 26.01 lbs (11.8 kg)
  • Connection Pipe Diameter Liquid 1/2" (12.70 mm)
  • Discharge Gas 3/4" (19.05 mm)
  • Suction Gas 1-1/8" (28.58 mm)
  • Operation Range Cooling 14 to 115 °FDB (-10 to 46 °CDB)
  • Heating -4 to 70 °FDB (-20 to 21 °CDB)
Item#:
AOUA120TLBV
Manufacturer Item:
AOUA120TLBV
Manufacturer:
FUJITSU
Fujitsu AOU48RLAVS Airstage Condenser Heat Pump Cool 48k BTU 54k BTU Heat 208/1 VAC R410A VRF
  • Power source Phase 1-phase
  • Voltage 208 / 230 V
  • Frequency 60 Hz
  • Capacity Cooling 48,000 BTU/h
  • Heating 54,000 BTU/h
  • EER (Non-Ducted/Ducted) Cooling 9.6 / 9.1 Btu/hW
  • SEER (Non-Ducted/Ducted) Cooling 18.8 / 16.9 Btu/hW
  • COP (Non-Ducted/Ducted) Heating 3.54 / 3.36 W/W
  • HSPF (Non-Ducted/Ducted) Heating 10.9 / 10.1 Btu/hW
  • Air Flow Rate 2,472 CFM (4,200 m/³h)
  • Sound Pressure Level*2 Cooling 53 dB(A)
  • Heating 55 dB(A)
  • Net Dimensions Height 39-5/16" (998 mm)
  • Width 38-3/16" (970 mm)
  • Depth 14-9/16" (370 mm)
  • Net Weight 194 lbs (88 kg)
  • Refrigerant Type R410A
  • Charge 8.82 lbs (4.0 kg)
  • Connection Pipe Diameter Liquid 3/8" (9.52 mm)
  • Discharge Gas 5/8" (15.88 mm)
  • Operation Range Cooling 23 to 115 °FDB (-5 to 46 °CDB)
  • Heating -4 to 70 °FDB (-20 to 21 °CDB)
Item#:
AOU48RLAVS
Manufacturer Item:
AOU48RLAVS
Manufacturer:
FUJITSU
Fujitsu ARUH36TLAV Airstage Indoor High Static Duct Pressure 36k BTU 208/1 VAC
  • Auto Switching Heat Cool : No
  • BTU Cooling Rating: 36000 Btu/h
  • BTU Heat Rating: 40000 Btu/h
  • Collection: Airstage VR-II
  • Decibel Rating dB : 43 dB
  • Depth: 19-11/16 in
  • Energy Star Compliant: Yes
  • Green: [Yes, Energy Star]
  • Height: 15-3/4"
  • Indoor Outdoor: Indoor
  • Installation Type: Ceiling Mount
  • Liquid Line OD : 3/8"
  • MBH: 36
  • MaX CFM: 1324
  • Phase: Single Phase
  • Power Source: Electric
  • Refrigerant: R-410A
  • SEER: 19.8
  • Stages: Two
  • Suction Line OD : 3/4"
  • Tonnage: 3 Tons
  • UL Listed: No
  • Volts: 208/230V
  • Width: 41-11/32 in
Item#:
ARUH36TLAV
Manufacturer Item:
ARUH36TLAV
Manufacturer:
FUJITSU
Fujitsu ARUH60TLAV Airstage Indoor High Static Duct Pressure 60k BTU 208/1 VAC
  • Auto Switching Heat Cool : No
  • BTU Cooling Rating: 60000 Btu/h
  • BTU Heat Rating: 67000 Btu/h
  • Collection: Airstage VR-II
  • Decibel Rating dB : 48 dB
  • Depth: 19-11/16 in
  • Energy Star Compliant: Yes
  • Green: [Yes, Energy Star]
  • Height: 15-3/4"
  • Indoor Outdoor: Indoor
  • Installation Type: Ceiling Mount
  • Length: 25-3/16"
  • Liquid Line OD : 3/8"
  • MaX CFM: 1972
  • Phase: Single Phase
  • Refrigerant: R-410A
  • SEER: 19.8
  • Stages: Two
  • Suction Line OD : 3/4"
  • Tonnage: 5 Tons
  • UL Listed: No
  • Volts: 208/230V
  • Width: 41-11/32 in
Item#:
ARUH60TLAV
Manufacturer Item:
ARUH60TLAV
Manufacturer:
FUJITSU
Fujitsu ASUA14TLAV1 Airstage Wall Mount Indoor Evaporator Cool 14,000k BTU 15,600 Heat 208/1
  • Power Source 208 / 230V, 1-Phase, 60Hz
  • Connection Pipe Diameter - Liquid (Flare)1/4" Flare
  • Connection Pipe Diameter - Gas (Flare) 1/2" Flare
Item#:
ASUA14TLAV1
Manufacturer Item:
ASUA14TLAV1
Manufacturer:
FUJITSU
