Evaporator Coil Cased 2-1/2 Ton W/Power-V Technology Upflow/Downflow

Item #:EVD4X30M14A
Manufacturer Item: EVD4X30M14A
Manufacturer: INTERNATIONAL COMFORT PRODUCTS
ICP EVD4X30M14A Evaporator Coil Cased
Cased/Uncased: Cased - Tonnage: 2 - Refigerant: R410A: Configuration: Upflow/Downflow - Coil Type: V-Coil
EVD4X30M14A
  • Performance  Designed with performance in mind, this new evaporator coil offers lower pressure drops to enhance system performance and airflow characteristics.
  • Thermostatic Expansion Valves (TXV)  All coils have refrigerant-specific, factory-installed TXVs. All models are factory pre-set to approximately 10° of superheat at the suction service valve.
  • Durable Condensate Pan  The corrosion-resistant drain pan is designed of a Polybutylene terephthalate material (PBT) that offers unsurpassed pan strength. It is engineered with proper slope to help ensure water drainage, improved moisture removal, and home comfort. Condensate Drain Pan Plugs  The drain pan is supplied with three water-tight drain plugs to prevent leakage from unused drain connections.
  • Refrigerant Connections  Provided with industry proven sweat connections for leak-free operation to maintain system reliability. The location of the lineset connections allows for removal of the access door for easy cleaning/servicing of the coils, as well as easy access to the TXV. All models come from the factory with enough length of straight tubeonce the pipe swages are cut offto accommodate braze-less compression fittings.
  • Burst Pressure  Meets or exceeds burst pressure of 1900 psi, which is at least three times the maximum operating pressure it would see in actual cooling-only application.
  • UV Knockout  This cased coil comes with factory-installed UV knockouts for quick and easy installation of UV lights.
  • Serviceability  Comes with a no delta plate for easy, quick access to both sides of the coil for service and cleaning. Also, after the door is removed and refrigerant lines disconnected, the coil is removable from the front of the unit without the use of any tools.

    Browning Belt A74

    • Evaporator Coils

    Brand Name
    International Comfort Products
    Cased/Uncased
    CASED
    BTU
    30000
    Tonnage
    2
    Configuration
    Upflow/downflow
    Coil Type
    V-COIL
    Refrigerant
    R410A
    Length
    20-5/8"
    Width
    14-3/16"
    Height
    17-1/16"
